Hot Water Bath

Mainly used for distilling, drying, concentrating, and soaking chemicals or biological products in the laboratory.
Material: Inner SS 304/201, the shell is made of plastic sprayed steel plate.

Product Features of our Hot Water Bath:

1. Removable ABS cap: the hold can be changed according to the user's specification, making the experiments more convenient.

2. 3-D circulation heating, more accurate temperature control, and more lasting constant temperature.

3. The built-in water barrier board effectively protects the heating pipe and improves the load capacity.

4. A separate drain port can effectively prevent the liquid from penetrating the water bath and causing damage to the instrument.

5. Digital Control panel, more accurate temperature control and easy operation.

Main Technical Data of the Water Bath:

Temperature Range: Room temperature-100℃
Power Supply: 220V/50Hz

User's Manual of our Water Bath:

1. Please input enough water into the water bath before use, then connect it to the power supplies.
2. Press the "set" key to enter the temperature setting mode or to see the setting value. Press "set" once, and if we can see the digital flashing, we are in the temperature setting mode. Press the "up" key to add the value, and press "down" to reduce the value. We can also press the key and keep holding the key down till the required value, then press the "set" key again to exit the setting mode.
3. Press the "set" key again after all the parameters finish setting to go back to normal working mode.

Precautions for using the water bath:

1. Do not put too much water to prevent the water from overflowing when boiling.
2. The water level should be higher than the heating pipe position, or the heating pipe will be damaged.
3. This machine adopts three pin plug. Make sure it is properly grounded.
4. The inner water temperature may not be so even if it is measured during the heating period, so please measure it when it is stable.
5. Please do not break the temperature probe in the middle of the heating pipe. Or the measured temperature will not be so accurate.
